OS-1500-SS | $33,000 list

1,500 Gallon Oil Separator with Slick Stick™

Downloads

Specifications
Revit
RFA
Install & Maint. (OS-1500)
PDF
Install & Maint. (Slick Stick™)
PDF
Optional Coalescing Media
CS3
Flow Rate
314 GPM
Weight
1,700 lbs.
Tank is fabricated to accept Slick Stick™

CAPACITIES

Total
1,500 gal. / 200 cu. ft.
Oil
610 gal.
Sand
486 gal.

DIMENSIONS

L x W x H
120" x 68" x 77"

CONNECTIONS

Inlet & Outlet
6" plain end
Vent
4" plain end

MATERIAL OF CONSTRUCTION

Tank
1" thick polyethylene
Covers
Traffic-rated bolted composite

Slick Stick™

UL Listed
NEMA 4X weatherproof enclosure
120 volt power required
Provides audible and visual indicator when oil level is met
Unit supplied with extra dry contact for BMS hookup
