OS-75

High Efficiency Oil/Water Separator

75 GPM | 99% Efficient

Listed by IAPMO to IGC 325

$4,100 list

Ships in: 3 business days

Downloads:

Specifications
Revit
RFA
Slab Detail
DWG
Install & Maint.
PDF
  • Flow Rate

    75 GPM

  • Weight

    120 lbs.

CAPACITIES

  • Total

    110 gal. / 14.7 cu. ft.

  • Oil

    27.5 gal.

  • Sand

    11 gal.

DIMENSIONS

  • L x W x H

    46" x 32" x 38-1/2"

CONNECTIONS

  • Inlet & Outlet

    4" plain end

  • Vents

    3" plain end

MATERIAL OF CONSTRUCTION

  • Tank

    Polyethylene

  • Cover

    Composite

CONNECTIONS

  • Inlet & Outlet

    6" plain end (-6P)

COVER

RISERS

BURIAL DEPTH (COVER-TO-GRADE)

  • Up to 5":

    Included with cover adapter

  • Up to 24":

    SR-24

  • Up to 39":

    LR-24

  • Up to 43":

    SR-24 (x2)

  • Up to 58":

    SR-24 + LR-24

  • Up to 72":

    LR-24 (x2)

  • -OR-

  • 11" - 72":

    CPRK (corrugated pipe by others)

Oil Level Monitoring System

High Water Hold Down Kit
