OT-1500-SS | $32,000 LIST

1,500 Gallon Oil Separator with Slick Stick™

Downloads

Specifications

PDF DWG

Revit

RFA

Install & Maint. (OT-1500)

PDF

Install & Maint. (Slick Stick™)

PDF

Optional Coalescing Media

CS3

Flow Rate

314 GPM

Weight

1,600 lbs.

Tank is fabricated to accept Slick Stick™

CAPACITIES

Total

1,500 gal.

Oil

858 gal.

Sand

542 gal.

DIMENSIONS

LxWxH

132" x 67 3/4" x 80"

CONNECTIONS

Inlet & Outlet

6" plain end

Vent

3" plain end

MATERIAL OF CONSTRUCTION

Tank

1" thick polyethylene

Covers

H20 rated pickable cast iron

CONNECTIONS

Inlet & Outlet

4" plain end (-4P)

4" male thread (-4M)

6" male thread (-6M)

8" plain end (-8P)

RISERS

Up to 2": Included with cover adapter

N/A

Up to 24": SR-24 (x3)

$1,920 list

Up to 39": LR-24 (x3)

$2,280 list

Up to 43": SR-24 (x6)

$3,840 list

Up to 58": SR-24 (x3) + LR-24 (x3)

$4,200 list

Up to 72": LR-24 (x6)

$4,560 list

Up to 90": SR-24 (x3) + LR-24 (x6)

$6,480 list

Up to 106": LR-24 (x9)

$6,840 list

-or-

11" - 106": CPRK (x3)*

$1,770 list

*corrugated pipe by others

COALESCING MEDIA

Single (-CS3)

$2,650 list

HIGH WATER ANCHOR KIT

HDK-6

$1,210 list

NEW PRODUCT!

OT-1500-SS replaces the OS-1500-SS.
