OS Series

Hydrocarbons aren’t healthy for our soil, waterways, and sewers. Let’s catch them.

Common Applications

  • 01. Vehicle service / repair stations
  • 02. Fire houses and police stations
  • 03. Hydraulic elevator pit waste
  • 04. Car washes
  • 05. Parking garages
  • 06. Loading docks
  • 07. Airports/hangars

OS-15

15 GPM Oil Separator

$1,260 list

Flow Rate
15 GPM
Weight
30 lbs.

CAPACITIES

Total
15 gal. / 2 cu. ft.
Oil
10 gal.
Sand
1 gal.

DIMENSIONS

L x W x H
25" x 19" x 14-1/4"

Downloads

Specifications
Revit
RFA
Install & Maint.
PDF

OS-25

25 GPM Oil Separator

$1,560 list

Flow Rate
25 GPM
Weight
33 lbs.

CAPACITIES

Total
21 gal. / 3 cu. ft.
Oil
15 gal.
Sand
6 gal.

DIMENSIONS

L x W x H
27" x 21" x 15"

Downloads

Specifications
Revit
RFA
Install & Maint.
PDF

OS-35

35 GPM Oil Separator

$2,060 list

Flow Rate
35 GPM
Weight
76 lbs.

CAPACITIES

Total
38 gal. / 5 cu. ft.
Oil
28 gal.
Sand
6 gal.

DIMENSIONS

L x W x H
33" x 25" x 25"

Downloads

Specifications
Revit
RFA
Install & Maint.
PDF
Optional Coalescing Media
CS1

OS-50

50 GPM Oil Separator

$2,400 list

Flow Rate
50 GPM
Weight
93 lbs.

CAPACITIES

Total
57 gal. / 7 cu. ft.
Oil
40 gal.
Sand
7 gal.

DIMENSIONS

L x W x H
37" x 28" x 28-1/2"

Downloads

Specifications
Revit
RFA
Install & Maint.
PDF
Optional Coalescing Media
CS1

OS-75

75 GPM Oil Separator

$3,440 list

Flow Rate
75 GPM
Weight
120 lbs.

CAPACITIES

Total
110 gal. / 14 cu. ft.
Oil
93 gal.
Sand
11 gal.

DIMENSIONS

L x W x H
46" x 32" x 38-1/2"

Downloads

Specifications
Revit
RFA
Install & Maint.
PDF
Optional Coalescing Media
CS2

OS-100

100 GPM Oil Separator

$6,200 list

Flow Rate
100 GPM
Weight
225 lbs.

Capacities

Total
250 gal. / 33 cu. ft.
Oil
144 gal.
Sand
95 gal.

Dimensions

L x W x H
68" x 33" x 51-1/2"

Downloads

Specifications
Revit
RFA
Install & Maint.
PDF
Optional Coalescing Media

OS-500

500 Gallon Oil Separator

$12,400 list

Flow Rate
100 GPM
Weight
530 lbs.

CAPACITIES

Total
500 gal. / 66 cu. ft.
Oil
288 gal.
Sand
95 gal.

DIMENSIONS

L x W x H
136" x 33" x 51-1/2"

Downloads

Specifications
Revit
RFA
Install & Maint.
PDF

OS-750

750 Gallon Oil Separator

$16,800 list

Flow Rate
314 GPM
Weight
1,090 lbs.

CAPACITIES

Total
750 gal. / 100 cu. ft.
Oil
401 gal.
Sand
307 gal.

DIMENSIONS

L x W x H
81" x 68" x 77"

Downloads

Specifications
Revit
RFA
Install & Maint.
PDF
Optional Coalescing Media

OS-1000

1,000 Gallon Oil Separator

$20,600 list

Flow Rate
314 GPM
Weight
1,215 lbs.

CAPACITIES

Total
1,000 gal. / 133 cu. ft.
Oil
451 gal.
Sand
347 gal.

DIMENSIONS

L x W x H
90" x 68" x 77"

Downloads

Specifications
Revit
RFA
Install & Maint.
PDF
Optional Coalescing Media

OS-1500

1,500 Gallon Oil Separator

$28,100 list

Flow Rate
314 GPM
Weight
1,350 lbs.

CAPACITIES

Total
1,500 gal. / 200 cu. ft.
Oil
610 gal.
Sand
486 gal.

DIMENSIONS

L x W x H
120" x 68" x 77"

Downloads

Specifications
Revit
RFA
Install & Maint.
PDF
Optional Coalescing Media

Polyethylene Construction

Easy to install and corrosion-resistant for a lifetime of use.

Field-adjustable Extensions

Make the cover flush with grade with stackable risers, easily cut on site.

Easy to Size

Size based on flow rate or total capacity, with tanks ranging from 15 to 1500 gallons.

Not sure which size you need?

Check out our oil separator sizing tool. It only takes 20 seconds.

Start Sizing

Don’t guess when it’s time to pump out your oil separator.

Our Slick Stick™ Oil Level Monitoring Solution will let you know.

Check It Out
